Although Xamarin enables development for all three major mobile platform in C# and
.Net, the build process of Xamarin apps on iOS, Android and Windows Phone is
very different. We will see this from window of obfuscation and security to make
app code and sensitive information within app protected and less vulnerable to
hacking efforts. Let’s visit each platform one by one.
iOS
The iOS does not allow JIT (just in time) compiling. Instead all C# code goes through
the AOT (ahead of time) compiler. The end result is, all the IL code from your
assemblies is being converted into native ARM (v6, v7 and so on) instructions.
This way the IL is not required anymore. So when you're building for Release|iPhone
configuration, the IL code will be removed from your assemblies. And since it
is not present, there is no need to obfuscate. Off course one can still reverse
engineer AOTed code but it is fairly hard compare to any .net assembly which
compiles to IL. Note that .NET assemblies will still be inside the IPA package
because the metadata is still required by System.Reflection. So if you view those
assemblies in any good .Net reflector, you will see symbol names and resources
files.
Android
In Xamarin Android, C# is compiled to IL and packaged with MonoVM + JIT’ing. The
generated APK for Release configuration contains mono runtime along with your
android application assemblies. . For obfuscation purpose, we will make use of
Crpyto Obfuscator as it is popular among Xamarin applications and .NET. You can
get the trial of it at:
http://www.ssware.com/cryptoobfuscator/obfuscator-net.htm
Once it is installed, you will see that it has nice interface to add assembly or
add XAP files for obfuscation. You can even incorporate the Crypto obfuscation
process right in Visual Studio using Visual Studio Project Integration Wizard.
This will obfuscate when you do build for your project.
Figure 1.0 Crypto Obfuscator user interface
We will use DotPeek from JetBrains to decompile the assembly for Windows Phone and Android projects.
Download the tool and install. Now let’s create sample Xamarin Android application
project, compile it and open the compiled assembly in DotPeek. You will see something
as per Figure 1.1.
Figure 1.1 Decompiled AndroidApplication2.dll
Now, let’s obfuscate our application using Crypto Obfuscator. For this, I chose to
go through Visual Studio Project Integration Wizard and choose Release Any CPU
for obfuscation target. Once I save the project in Crypto Obfuscator, it adds
entry in AndroidApplication2.csproj and adds custom build step that obfuscates
the code while building. Once you successfully integrate Crypto Obfuscator, when
you build for Release Any CPU, the Visual Studio Output window will show you
that Crypto Obfuscator is at its job!
Figure 1.2 Crypto Obfuscator message in Visual Studio Output window
Now quickly grab the AndroidApplication2.dll from Release folder and again open it
in DotPeek. You will see that GUID generated names are used for the fields as
well some fake code is added as per Figure 1.3.
Figure 1.3 Decompiled AndroidApplication2.dll with obfuscation
Windows Phone
Xamarin for Windows phone compiles C# to IL and executed under built in runtime and
thus does not require any xamarin tools. The application gets packaged in to
XAP file which is standard zip file and you can view the contents using any zip
viewer. open PhoneApp1.dll in dotPeek.
Figure 1.4 Decompiled PhoneApp1.dll
As you see, the decompiled code is pretty simple to understand and manipulate. Let’s
add some obfuscation bit to it. I chose to try SmartAssembly from RedGate as I usually found their products are of good quality. You can use
Crypto Obfuscator as well but as I was exploring different tools, I chose SmartAssembly.
SmartAssembly has a nice interface to configure various aspect of obfuscation
and optimization as shown in Figure 1.5
Figure 1.5 SmartAssembly user interface
You can select an assembly to obfuscate. With the obfuscation applied, the same decompiled
dll looks like Figure 1.6.
Figure 1.6 Obfuscated PhoneApp1.dll
Off course, dotPeek is great decompiler and I have used pretty much default and very
light obfuscation settings, you will see that few part of code is still readable
and few part is obfuscated with fake code making use of label and goto statements.
SQLCipher
What if your app deals with sensitive data and stores it on device in the form of
embedded database such as SQLite? SQLCipher provides strong security for mobile
and embedded database using AES-256. I am leaving it up to you to give it a try
from the following link below.
http://components.xamarin.com/view/sqlcipher-for-xamarin/
Note that it supports Xamarin android and iOS applications.
Tools used in this article
Since I mentioned a few tools, here is the summary of all the tools used in this
article.
DotPeek from Jetbrains
http://www.jetbrains.com/decompiler/
Crypto Obfuscator
http://www.ssware.com/cryptoobfuscator/obfuscator-net.htm
Smart Assembly
http://www.red-gate.com/products/dotnet-development/smartassembly/
